V-200 Van Refrigeration Units

KingClima V-200 Van Refrigeration Units are rooftop mounting, driven by vehicle engine and apply for 5 -12 m³ van container box.

Model : V-200

Cooling Capacity： 2000W(0℃）1110W（-18℃）

Application : 5 -12m³

Compressor : DY5H11 / 108cc/r

Introduction

Technical Data :

Features :

Application

INQUIRY

Introduction

Brief Introduction of V-200 Van Freezer Unit

KingClima V-200 Van Refrigeration Units are rooftop mounting, driven by vehicle engine and apply for 5 -12 m³ van container box. V-200/V-200C van reefer units apply to small van or and medium refrigerated cargo vans with 5-12m³ van body box.

The van refrigeration units with chiller and freezing function for transporting fresh fruits, milk ,ice cream ,vegetables, meat, dairy products and seafood…

KingClima V-200 Freezer Unit for Van Optional Functions

● AC220V/1Ph/50Hz or AC380V/3Ph/50Hz
● Optional electric standby system AC 220V/380V

Technical Data :

Model		V-200
Temperature Range In Container		-18℃ ~ +15℃
Cooling Capacity		2000W(0℃）1110W（-18℃）
Driven Model		Direct Vehicle Engine Driven
Voltage DC (V)		12V/24V
Refrigerant		R404a
Refrigerant Charge		0.8Kg ~ 0.9Kg
Box Temperature Adjustment		Electronic digital display
Safety Protect		High and low pressure switch
Defrosting		Defrosting and heating optional
Compressor	Model	DY5H11
	Displacement	108cc/r
Condenser	Coil	Aluminum micro-channel parallel flow coils
	Fan	1 Axial Fan
	Dimensions&Weight	700×700×190 mm & 14.5 kg
Evaporator	Coil	Aluminum foil with internal ridge copper tube
	Fan	1Axial Fans
	Dimensions&Weight	610×550×175 mm & 13.5 kg
Box Volume (m³)	0℃	10m³
	-18℃	6m³
Optional Function		Heating, Electric standby system AC 220V/380V, CPR Valve

Features :

KingClima V-200 Cargo Van Freezer Unit Features:

● Apply for all kinds of small refrigeration vans
● The units with CPR valve will better protect compressors, especially in extremely hot or cold place.
● Adopt Eco-friendly refrigerant: R404a
● The Hot gas defrosting system with Auto and manual is available for your choices
● Rooftop mounted unit and slim evaporator design
● Strong refrigeration,cooling fast with short time
● High-strength plastic enclosure,elegant appearance
● Quick installation,simple maintenance an low maintenance cost
● Famous brand compressor:such as Valeo compressor TM16,TM21,QP16,QP21 compressor ,
Sanden compressor, highly compressor etc.
● International Certification : ISO9001,EU/CE ATP ,etc

Application

KingClima V-200 model is van freezer unit, which is designed for delivery deep frozen products. It is very popular in refrigerated van conversion field. For the long time frozen demands, customers can also equip with an electric standby system to connect AC 220V/380V voltage.

KingClima V-200 Van Refrigeration Unit
